Chemical name : 3-Isocyanatomethyl-3,5,5-trimethylcyclohexyl isocyanate
Alias : 3-Isocyanatomethyl-3,5,5-trimethylcyclohexyl isocyanate; 5-Isocyanato-1-(isocyanatomethyl)-1,3,3-trimethylcyclohexane; IPDI
IPDI products are mixtures containing 75% cis and 25% trans isomers.
Molecular Formula
C12H18N2O2
Relative Molecular Mass
222.29.CAS
CAS No.
4098-71-9.
EINECS No.
223-861-6
Physical and Chemical Properties
Isophorone Diisocyanate IPDI is colorless or light yellow liquid with camphor-like odor, completely miscible with esters, ketones, ethers, aromatic hydrocarbons and aliphatic hydrocarbons and other organic solvents.
Density
1.056
Melting point
– 60°C
Boiling point
158°C (15 mmHg)
Refractive index
1.484
Flash Point
>110°C
Water Solubility
<0.1 g/100 mL at 25°C
Performance Indicators
The specifications for IPDI products (brand name Desmodur I) are:
Purity
≥99.5 %
Mass fraction of NCO
≥37.5%
Color (Hazen)
≤30
Hydrolyzed chlorine
≤200 mg/kg
Total chlorine
≤400 mg/kg
Viscosity (25℃)
Approx. 10 mPa-s.
Safety data
Hazardous material symbol
T;N
Hazardous category code
r22;r36/37/38;r42/43;r51/53
Safety instructions
s26;s28;s38;s45;s61
Dangerous Goods Transportation Number
UN 2290/2906
Properties and Uses
IPDI is an aliphatic isocyanate, isophorone diisocyanate IPDI is also a kind of cycloaliphatic isocyanate, isophorone diisocyanate IPDI reactivity is lower than the aromatic isocyanate, and the vapor pressure is also lower. The reactivity of 2 NCO groups in isophorone diisocyanate IPDI molecule is different, because the primary NCO in IPDI molecule is hindered by the cyclohexane ring and a-substituted methyl group, which makes the reactivity of the secondary NCO group connected to cyclohexane is 1.3-2.5 times higher than that of the primary NCO; the reactivity of IPDI and hydroxyl group is 4-5 times faster than that of HDI and hydroxyl group.
The polyurethane resin made of isophorone diisocyanate IPDI has excellent light stability and chemical resistance, isophorone diisocyanate IPDI is generally used in the manufacture of high-grade polyurethane resins, such as light-resistant and marble-resistant polyurethane coatings, abrasion-resistant and hydrolysis-resistant polyurethane elastomers, and isophorone diisocyanate IPDI is also used in the manufacture of non-yellowing microcellular polyurethane foam.
